The Intersect node will output the intersection of two Vectron inputs (figure 1).


INTERSECT OPERATOR


Figure 1: A blue capsule Vectron object intersecting with a red cube Vectron object


Intersect Parameters

Bounds - Determines the bounds of the Vectron geometry.

Input 1 - The base Vectron object.

Input 2 - The Vectron object that will intersect Input 1.

Radius - Increases the intersection area, higher values will produce smoother results.

Transfer Material - If enabled, the material on the second input will be kept on the intersecting results.
